Key Features
- Takes Samples Direct From The Press Output Conveyors
- Tests Up to 1800/2400 Ends Per Hour
- True Micro Leak Test (3×10-6 cc/sec)
- Automatic Reject Logging & Ejection
- Can Provide Data Signals for Logging & Press Control
- No Operator Judgment Required
- Fully Automatic Operation
- Non-Destructive Test
- Automatic Self Calibration Using Traceable Reference Leaks
- PLC Controlled
- Results on Local Colour Display
| Leak Ranges | |
|---|---|
| Gross Leak | > 1 Atm. cc/sec. |
| Medium Leak | 1 to 0.05 Atm. cc/sec. |
| Micro Leak | 0.05 to 0.000003 Atm. cc/sec. |
| Test Modules | |
| Throughput | Up to 2400 ends / hour |
| Exit | Stacker tubes or Bagging table |
| End Size | All standard end sizes |
| Dropper | Optional extra to allow use of markers and manual testing of ends |
| Services Required | |
| Power | 3-phase, 380–415v, 5 amps, 50/60Hz |
| Compressed Air | Dry Air @ 6 Bar |
| Helium | Helium @ 2 Bar |
| Dimensions | |
| Overall | 800mm(L) × 900mm(W) × 2000mm(H) 800mm(L) × 1050mm(W) × 2000mm(H) |
